SPECIFICATIONS

Description:

The Defender series is proud to introduce its newest upgrade, equipped with the cutting-edge DJI O4 Air Unit Pro, delivering an unparalleled aerial filming experience. With enhanced transmission, crystal-clear imaging, and ultra-low latency, the Defender 25 sets a new standard for performance and reliability.

Get ready to push boundaries—Let's meet the all-new Defender 25.

Highlights

Ultralight & Free to Fly

Small But Mighty

The built-in 2.5inch propeller guards were designed to fly bold. You'll experience a complete new creative freedom to fly whenever and wherever. The durable injection molded frame does not only prevent damage to your motors or propellers, but also protects the environment of small flight errors.

O4 Video Transmission, Enhanced Perception

Crash Protected Quick-Release Battery

Innovative quick-release battery and charging adapter to make everything as easy as it can be. The Defender25 comes with a stock 4S 550mAh. An Endurance 900mAh battery is optional.

Inbuilt high-performance Video and Receiver antennas

Optimized Landing Gear for Take-off in Complex Environment

Countless easy-to-use features let you get started right away:

1) Secured XT30 Battery Plug with Anti-Spark Filter

2) Motors with direction arrows

3) Props with positioning column for easy installation

4) All ports and buttons are easy to access

5) Mini camera mount (Naked GoPro, Insta360, etc.)

Specifications

• Product Name: Defender25 O4 4S HD

  Flight Electronics: BLITZ D25 F7 AIO

  Video Transmission: DJI O4 Air Unit Pro

  Frame: 112±2mm

  Motor: Defender25 1404

  Prop: Defender25 2525 props (2.5 inch)

  Weight of the Aircraft: 170±5g

  Maximum Takeoff Mass incl. 550mAh battery: ≤249g

  Maximum Takeoff Mass incl. 900mAh battery: ≤280g

  Dimensions (L×W×H): 158x155x69mm

  Max Speed: 100km/h (Manual Mode)

  Maximum Takeoff Altitude: 3500m

  Max Hover Time: Approx. 6 mins(with 550mAh battery), 10mins(with 900mAh battery)

  Max Flight Distance: 2-3 km

  Max Wind Speed Resistance: Level 4

  Operating Temperature Range: -10° to 40° C (14° to 104° F)

  Antennas: Dual Antennas

  GNSS: GPS+SBAS+Galileo+QZSS+Glonass


Video Transmission

Product Name: DJI O4 Air Unit Pro

Image Sensor: 1/1.3-inch

Lens: FOV: 155°

ISO: 100-25600

Video Resolution: 1080p/100fps H.265

Video Format: MP4, Max Video Bitrate: 130Mbps

Color Mode: Normal Mode/D-Log M

Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled, the shooting angle only supports standard.)

Live View Quality: 1080P@100fps

Operating Frequency: 5.170-5.250 GHz & 5.725-5.850 GHz

Transmitter Power (EIRP): 5.1GHz23dBm(CE)/5.8GHz33dBm(FCC)/14dBm(CE)/30dBm(SRRC))

Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)

Communication Bandwidth: Max 60 MHz

Antenna: Dual antennas

Built-in Storage: 4GB

Supported SD cards: microSD (up to 512GB)

Operating Temperature: -10° to 40° C

Weight: Air Unit (camera module included): Approx. 32 g

Dimensions: Transmission Module: 33.5×33.5×13 mm (L×W×H)

Packing List

• 1 x Defender25 O4 HD BNF

  1 x Defender25 550mAh Battery

  1 x Type-C Charging Adapter

Recommended Charger:

Charger not included in combos, and sold separately.

To ensure charging speed, it is recommended to use Flight PD 100W Charger or PD 30W Charger, or other USB chargers that support USB PD and QC fast charging protocols.
